Electric Booster Assembly - 40°F/60°F Rise
1 113690 Heater, 12KW 208/60/3Ph (60°F)(200-220V/1Ph & 3PH) 1
113885 Heater, 12KW 220/230/240/380/415V 3Ph (60°F)(230-240/1PH & 3PH) 1
113886 Heater, 12KW 460/480V 3Ph (60°F) 1
113887 Heater, 12KW 575V 3Ph(60°F) 1
111233 Heater 7.5/10KW 240V 3Ph (40°F Rise)(200-220,230-240V/1PH) 1
111232 Heater, 10KW 208V 3PH (40°F Rise)(220-220/3PH) 1
111234 Heater, 10KW 480V 3PH (40°F Rise (480V 3PH) 1
111383 Heater, 10KW 575V3PH (40°F Rise)(480V 3PH) 1
2 109985 Seal, Electric Heater Flange 3
3 113724 Thermostat w/Capillary 210°F (Prior to S/N RE3932) 1
--- 110561 Thermostat w/Capillary, Fixed High Limit 240°F (After S/N RE3932) 1
4 108576 Cover, Booster No Cutout 1
5 109069 Thermostat w/ Capillary 1
6 102505 Plug 3/4” NPT Brass 1
7 414331 Tank Booster (40°F Rise) 1
8 113690 Heater, 12KW 208/60/3Ph (40°F)(200-220V/1Ph & 3PH) 1
113885 Heater, 12KW 220/230/240/380/415V 3Ph (40°F)(230-240/1PH & 3PH) 1
113886 Heater, 12KW 460/480V 3Ph (40°F)(460-480°/3PH) 1
112059 Heater, 12KW 208V 3Ph (60°F Rise)(200-220V/1PH & 3PH) 2
111334 Heater 12KW (60°F Rise) (230-240/1PH & 3PH) 2
112060 Heater 12KW (60°F Rise)(460-480/3PH) 2
112061 Heater 12KW 575V 3Ph (60°F Rise) 2
9 328254 Bracket, Front Booster 1
10 113706 Elbow Street 3/4 x 45 Brass (E-44) 1
11 108954 Nut Grip 6-32 w/Nylon Insert 1
12 328048 Clamp, Thermostat Booster Tank (Not shown, use with item 11) 1
13 111235 Heater, 5/6.6KW 208/240 (40° Rise)(200-220V/1PH & 3PH) 1
111236 Heater 5KW (40°F Rise)(230-240V1PH & 3PH) 1
111237 Heater 5KW (40°F Rise) (460-480V/3PH) 1
111384 Heater 5KW (40°F Rise) 575V 3PH 1
100003 Nut Plain 1/4-20 9
106482 Washer Lock 1/4 Split 9
100739 Bolt 5/16-18 x 3/4 Hex Head SST 4
106013 Washer Lock 5/16 Split 4
109205 Nut, Grip 5/16 w/Nylon Insert 4
107697 Nut Grip 1/4-20 w/Nylon insert 3
106026 Washer Flat 1/4”
Item Part Description Qty.
No. No.
