Champion 44 - Page 41


Two Tank Doors & Panels
1 327857 Door, E26" 2
2 108966 Door Handle 2
3 100073 Screw 1/4-20 x 1/2 Truss Head 8
4 113691 Guide, U-channel Door 4
5 329351 Panel, 25” End standard 1
6 328975 Panel, 64 Front Perimeter 1
7 328976-01 Panel, 84 Front Perimeter Right Hand 1
8 328976 Panel, 84 Front Perimeter Left Hand 1
9 113720 Curtain 24 x 20-1/4” (Load/Unload) 2
10 108250 Rod, Curtain 5/16 x 24-5/8” 4
11 108043 Curtain 24 x 13-1/4” (between wash and rinse) 1
--- 114012 Rod, Curtain, 5/16" x 23-5/8" (use with Item No. 11) 1
--- 109723 Curtain 24 x 6-1/4” (Rinse/Final Rinse)(Not Shown) 1
12 328030 Table Flange 2
13 113486 Screw 8-32 x 5/8 Flat Head SST 12
14 329926 Bafe 1
15 331981 Bracket, Door Stop 1
16 100141 Nut, Plain 1/4-20 SST 4
17 317345 Bracket, Door Catch 2
18 308133 Dual Hook, Door 1
19 108418 Plug, 1/2" 4
20 109034 Gasket 4
21 108417 Nut 4
22 113943 Plug, 3/4" 4
23 108602 Gasket 4
24 113944 Nut 4
25 329985 Bracket, Water Diverter 2
26 108954 Grip Nut, 6-32 w/nylon insert SST 16
27 113937 Magnet, Door 2
28 113719 Switch, Door Safety 2
29 100764 Screw, 6-32 x 1/2" Round Hd. SST 16
Item Part Description Qty.
No. No.
