Champion 44 - Page 45


Conveyor Drive Assembly
1 202381 Roller Crosshead 1
2 100868 Roller Stud Crosshead 1
3 107089 Nut Jam 1/2-13 1
4 206300 Crank, Rack Arm 1
5 206301 Shaft 5/8" O.D. x 8-3/8" LG. 1
6 206302 Housing, Bearing/Seal 1
7 102244 Seal 5/8” 1
8 206303 Gasket/Bearing Seal 1
9 100382 Bearing Jaf #EK104-10 1
10 100007 Screw, 10-32 x 3/8 Truss Head 1
11 104925 Washer 1/4 x 1 x 16 Gauge 1
12 103180 Wiper Ring 1
13 104916 Key 3/16 x 3/16 x 3/4 SST 1
14  1
15 
16 327924 Bracket, 44 Drive Bearing Mounting 1
17 113860 Bearing, Sealed 5/8 Bore 1
18 104923 Screw 1/4-20 x 3/8 Round Head 4
19 100739 Bolt 5/16-18 x 3/4 Hex Head SST 8
20 106013 Washer Lock 5/16 Split 8
21 102376 Washer, at 5/16" 8
22 100154 Nut Plain 5/16-18 SST 8
23 100746 Bolt 3/8-16 x 1-1/4" Hex Head 2
24 104618 Washer 3/8 x 7/8 x 1/16 SST 2
25 109010 Grip Nut, 3/8" w/nylon insert 2
Item Part Description Qty.
No. No.
