Champion 44 - Page 47


Prewash Track & Cradle Assembly
1 113719 Switch, Door Safety 1
2 328045 Bracket, E PW IdlePump 1
3 113937 Magnet, SS 1
4 100764 Screw, 6-32 x 1/2 Round Head SST 2
5 108954 Nut, Grip 6-32 Hex Head W/Nylon Insert 2
6 106482 Washer Lock 1/4 Split 2
7 327833 Pin Idle Switch lever 1
8 100736 Screw, 1/4-20 x 3/4" Hex Head 2
9 328041 Track, 22” PW Rear 1
10 328043 Cradle, 22” PW 1
11 204513 Pawl, Cradle 4
12 206345 Spacer, Rack Cradle Pawl 4
13 113692 Bolt, Shoulder, 3/8 x 3/4 x 5/16-18 x 3/8" SST 4
14 333155 Cradle, Drive Rod Single Tank, 22" PW 2
14 333155 Cradle Drive RodTwo Tank 22" PW or Single Tank E 36" PW 2
15 206343 Bearing, E Cradle Support 4
16 327955 Track, 22” PW Front 1
17 100735 Bolt 1/4-20 x 5/8" Hex Head SST 8
18 112318 Washer, Flat 1/4-20 8
19 100142 Nut, Grip 5/16-18 6
20 331988 Bracket, Lower Washarm Support 2
21 100734 Bolt, Hex. Hd. 1/4-20 x 1/2" 6
22 206920 Rod, Lower Washarm Support, Threaded 1
23 100141 Nut, Grip 1/4-20 8
24 106482 Washer Lock 1/4-20 Split 2
---- 414334 Cradle Assembly, Complete, PW22"
---- 414438 Cradle Assembly Complete, PW36"
---- 900897 Kit, Idle Pump Assy.
Item Part Description Qty.
No. No.
