Champion 44 - Page 49


Single Tank Track & Cradle Assembly
1 113719 Switch, Reed Aleph 1
2 414344 Switch, Idle Assembly (Includes Items 3-8)(Prior to 8/30/08) 1
3 113937 Magnet, SS 1
4 100764 Screw, 6-32 x 1/2 Round Head SST 2
5 108954 Nut, Grip 6-32 Hex Head W/Nylon Insert 2
6 106482 Washer Lock 1/4 Split 2
7 327833 Pin Idle Pump Switch 1
8 100736 Screw, 1/4-20 x 3/4 Hex Head 2
9 414370 Track, E44 Front 1
10 414307 Cradle, E44 1
11 113692 Screw, 3/8 x .875 x 5/15-18 8
12 206345 Bushing, Rack Cradle Pawl 8
13 204513 Pawl, NG Cradle 8
14 414357 Track, E44 Rear 1
15 206343 Bearing, Rack Cradle Slide 4
16 100412 Nut, Grip 5/16-18 1
17 100141 Nut, Grip 1/4-20 4
18 100736 Bolt 1/4-20 x 3/4 Hex Head SST 2
--- 106482 Washer Lock 1/4-20 Split 2
19 329295 Switch, Idle Weldment (After 6-30/08) (For DR, DRWS Models) 1
20 329783 Switch, Idle Assy. Weldment (After 6-30/08) (For WS, LT Models) 1
21 100734 Bolt, Hex. Hd. 1/4-20 x 1/2" 6
22 100142 Nut, Grip 5/16-18 2
23 331988 Bracket Lower Washarm Support 2
24 206920 Rod, Support 1
25 100735 Bolt 1/4-20 x 5/8" Hex Hd., SST 8
--- 414377 Cradle, E-44 Complete (Includes Items 10-13 and 16) 1
--- 329486 Track, 26" Front Feed Assy.
--- 900897 Kit. Idle Pump Assy.
Item Part Description Qty.
No. No.
