T
wo T
ank Scrap Screens
Item
Part
Description
Qty
.
No.
No.
1
414328
Screen, E-44 L-R Front
1
2
414329
Screen, E-44 L-R Rear
1
3
414300
Basket, Rack
1
4
331922
Support, Screen
4
5
328653
Screen, Outboard, (E-84 Only)
1
56
