Champion 44 - Page 59


Prewash Spray Arms
1 414569 Wash Manifold Assembly 6” Lower 1
2 113723 O-Ring,1.75 ID 1
3 113738 Block, Washarm Retaining 4
4 113540 Locknut 2NPT SST 2
5 113542 Gasket, Flat EDPM 2-3/8 ID 2
6 328028 Standpipe, 22” PW 1
7 414568 Wash Manifold Assy 6” Upper 1
8 328998 Bracket, Upper Safety 1
9 113555 Plug, Wash Arm E-Series (Qty per arm) 4
10 113716 O-ring 4
11 328634 Support, Upper Wash 1
12 106014 Nut, Acorn 1/4-20 SST 8
13 106482 Washer, Lock 1/4" Split SST 8
14 106026 Washer, Flat 1/4" SST 8
15 329000-1 Bracket 1
16 106141 Grip Nut, 1/4" SST 2
17 100735 Bolt, Hex Hd. 1/4-20 SST 2
18 329001 Support, Upper Wash 1
19 328253 Bracket Support 1
Item Part Description Qty.
No. No.
