Champion 44 - Page 63


Two Tank Wash & Rinse Spray Arms
1 113542 Gasket, Flat EDPM 2-3/8 ID 4
2 113540 Locknut 2NPT SST 4
3 113738 Block, Washarm Retaining 2
4 113723 O-ring,1.75 ID 2
5 414289 Wash Manifold Assembly 14” Straight Upper (L-R) 2
--- 414288 Wash Manifold Assembly 14” Straight Upper (R-L)
6 414291 Wash Manifold Assembly 10” 15° Lower (L-R) 2
--- 414290 Wash Manifold Assembly 10” 15° Lower (R-L) 2
7 414318 Standpipe 64 L-R Wash 1
--- 328443 Standpipe 64 R-L Wash 1
8 414319 Standpipe 64 L-R Rinse 1
--- 328445 Standpipe 64 R-L Rinse 1
9 113555 Plug, Wash Arm E-Series (Qty per arm) 4
10 113716 O-ring 4
11 106014 Nut, Acorn 1/4" SST 10
12 106482 Washer, 1/4" Split SST 8
13 328034 Support, Upper Washarm 2
14 106026 Washer, Flat 1/4" SST 8
15 100141 Grip Nut, 1/4" SST 4
16 328998 Bracket, Upper Safety 2
17 329000-1 Latch, E Upper Washarm Weldment (L-R Operation) 2
--- 329000-2 Latch, E Upper Washarm Weldment (R-L Operation) 2
18 329001 Bracket, Upper Washarm Support 2
19 100735 Bolt, Hex Hd. 1/4-20 x 5/8" SST 4
Item Part Description Qty.
No. No.
