Champion 44 - Page 83


Single & Two Tank Drain-overflow Assembly
1 113715 Ring, Retaining 2
2 328985 Lever Drain Lift 1
3 206442 Rod, Overow Lift 1
4 206444 Block, drain lift 1
5 107966 Nut, Grip 10-32 w/Nylon Insert 2
6 112257 O-ring 1
7 100735 Bolt 1/4-20 x 5/8 Hex Head 4
8 106026 Washer 1/4 x 5/8 x 1/6 SST 5
9 111532 O-ring, Drain 1.600 ID x .21 1
10 111034 Drain , Flange Cast/Mach SST 1
11 ---------- Overow 2-tank Wash Tank (Breakdown previous page) 1
---- ---------- Overow 2-tank Rinse Tank (Breakdown previous Page) 1
12 107367 Chain, Bead #10 2FT
13 107966 Grip Nut, 10-32 w/nylon insert SST 1
14 107368 Fitting, Chain End Coupling 2
Item Part Description Qty.
No. No.
