Final Rinse Piping with Booster
1 See Chart Below for Manifold P/N's
2 106026 Washer 1/4 x 5/8 x 1/16 SST 1
3 107967 Nut Grip 1/4-20 w/Nylon Insert 1
4 See Chart Below for Upper Nozzle P/N's 3
5 See Chart Below for Lower Nozzle P/N's 3
6 113795 Plug 11/16-16 Thread 2
-- 113716 Gasket Rinse Pipe (Not Shown) 1
7 100156 Locknut 3/4NPT Brass 1
8 100599 Cross 3/4” NPT Brass 1
9 105976 Bushing Red 3/4” NPT x 1/8” NPT Brass 1
10 101259 Plug 1/8” NPT Brass 1
11 100184 Nipple 3/4”NPT Close Brass 1
12 100571 Union 3/4”NPT Brass 1
13 102470 Nipple 3/4” NPT x 3” Lg Brass 1
14 102388 Bushing, Reducing 1/2”NPT x 1/4”NPT Brass 1
15 104429 Vacuum Breaker 3/4”NPT 1
16 900837 Kit*Repair, 3/4 Vacuum Breaker A/R
17 102525 Tee, Red 3/4” x 1/2” x 3/4” NPT Brass 1
18 109879 Fitting Compression 3/4”NPT x 7/8” OD 1
19 100171 Bushing Red Face 3/4” NPT x 1/2 NPT Brass 1
20 102490 Nipple 1/4”NPT x 3-1/2” Lg Brass 1
21 100135 Pressure Gauge 0-60 PSI 1
22 102442 Elbow 3/4 x 90° Brass 1
Item Part Description Qty.
No. No.
P/N P/N P/N - Dim. P/N - Dim.
E44/54
107290 112022 113699 - 25-3/4" 113694 - 25-3/4"
E44/54 HH
107290 112022 114023 - 29-3/4" 114022 - 29-3/4"
E44/54DR
180282 112022 329010 - 25-3/4" 329265 - 25-3/4"
E44/54DR HH
107290 112022 114023 - 29-3/4" 114022 - 29-3/4"
E44/54WS
0508376 112022 113699 - 25-3/4" 113694 - 25-3/4"
E44/54DRWS
0508376 112022 329010 - 25-3/4" 329265 - 25-3/4"
E64/84
107290 112022 113699 - 25-3/4" 113694 - 25-3/4"
E64/E84 HH
107290 112022 114023 - 29-3/4" 114022 - 29-3/4"
