Basic Service ________________
Mechanical Service •
Replace Electric Booster Control Thermostat
Basic Service • Mechanical
NOTE !
READ ALL OF THE THERMOSTAT INSTRUCTIONS
BEFORE YOU REPLACE THE CONTROL THERMOSTAT
USED IN AN ELECTRIC BOOSTER HEATER.
IMPROPER INSTALLATION CAN CAUSE FINAL RINSE
TEMPERATURE PROBLEMS.
WARNING !
ELECTRIC SHOCK may cause INJURY OR
DEATH.
DO NOT WORK ON AN ENERGIZED CIRCUIT.
Turn off the main power service disconnect switch.
Attach a label to the breaker indicating that work is
being made on the electrical circuit.
1. You will need a permanent marker such as a SHARPIE® or comparable in order
to mark the control thermostat capillary tube.
2. Do not crimp the thermostat capillary tube.
3. The ferrule cannot be repositioned after the gland nut has compressed the ferrule
on the capillary tube.
4. The control thermostat fitting is located on the left underside of the booster tank
when viewing the booster tank from the front.
