Champion Simplex - Page 23

Simplex Control Panel 23 CQF3475 v.02
Operation & Service August 06, 2019
Section 5 – Parts List (cont.)
5.1 No Protection Circuit - 115V
PANEL PART #
HP
VOLTAGE
PHASE
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
TEN004649
.5
115
1
TEN001131
VP1039723
TEN004656
.75
115
1
TEN001131
TEN005493
TEN004656
1
115
1
TEN001131
TEN005493
TEN004661
1.5
115
1
TEN001131
TEN005494
TEN004666
2
115
1
TEN001131
TEN005495
TEN004991
3
115
1
TEN005627
VP1039727
ITEM
PART #
DESCRIPTION
QTY
3
24CA5991
DIN RAIL
1
4
24CA5984
TERMINAL BLOCK
5
5
24CA5987
TERMINAL BLOCK, END STOP
2
6
24CA2898
FUSE 000.80A
1
7
24CA7198
FUSE HOLDER
1
8
24CA7881
GROUND LUG
2
9
24CA5985
TERMINAL BLOCK,END PLATE
1
10
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
