Champion Simplex - Parts List; No Protection Circuit - 115 V

Simplex Control Panel 22 CQF3475 v.02
Operation & Service August 06, 2019
Section 5 – Parts List
Part Numbering for Control Panels: Add the following suffix to the "PANEL PART #" listed on the following pages.
No suffix
NEMA 1 CONTROL PANEL
-N4
NEMA 4 CONTROL PANEL
-L2
NEMA 1 CONTROL PANEL, WITH HOUR METER AND SELECTOR SWITCH
-N4-L2
NEMA 4 CONTROL PANEL, WITH HOUR METER AND SELECTOR SWITCH
5.1 No Protection Circuit - 115V
1
3
5
9
7
6
8
5
4
2
