Section 5 – Parts List (cont.)
5.2 No Protection Circuit - 208V, 230V, & 460V
PANEL
PART #
HP
VOLT
PH
ITEM 1
ITEM 2
PANEL
PART #
HP
VOLT
PH
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
CONTACTOR
OVERLOAD
TEN004650
.5
208
1
TEN001131
VP1039722
TEN004791
1.5
230
3
TEN001131
VP1039723
TEN004653
.5
230
1
TEN001131
VP1039721
TEN004664
1.5
460
3
TEN001131
VP1039721
TEN004657
.75
208
1
TEN001131
VP1039723
TEN004792
2
208
3
TEN001131
TEN005493
TEN004658
.75
230
1
TEN001131
VP1039722
TEN004791
2
230
3
TEN001131
VP1039723
TEN004657
1
208
1
TEN001131
VP1039723
TEN004668
2
460
3
TEN001131
VP1039722
TEN004660
1
230
1
TEN001131
VP1039723
TEN004792
3
208
3
TEN001131
TEN005493
TEN004662
1.5
208
1
TEN001131
TEN005493
TEN004793
3
230
3
TEN001131
TEN005493
TEN004663
1.5
230
1
TEN001131
TEN005493
TEN004672
3
460
3
TEN001131
VP1039723
TEN004667
2
208
1
TEN001131
TEN005496
TEN004794
5
208
3
TEN001131
TEN005496
TEN004669
2
230
1
TEN001131
TEN005496
TEN004795
5
230
3
TEN001131
TEN005496
TEN004670
3
208
1
TEN001131
TEN005494
TEN004674
5
460
3
TEN001131
TEN005493
TEN004671
3
230
1
TEN001131
TEN005494
TEN004796
7.5
208
3
TEN001131
TEN005494
TEN004670
5
208
1
TEN001131
TEN005494
TEN004797
7.5
230
3
TEN001131
TEN005494
TEN004671
5
230
1
TEN001131
TEN005494
TEN004674
7.5
460
3
TEN001131
TEN005493
TEN004676
7.5
208
1
TEN005627
VP1039727
TEN004798
10
208
3
TEN005627
VP1039727
TEN004677
7.5
230
1
TEN005627
VP1039727
TEN004799
10
230
3
TEN005627
VP1039727
TEN004654
.5
208
3
TEN001131
VP1039721
TEN004679
10
460
3
TEN001131
TEN005496
TEN004787
.5
230
3
TEN001131
VP1039720
TEN004681
15
208
3
TEN005627
TEN005535
TEN004655
.5
460
3
TEN001131
VP1039720
TEN004799
15
230
3
TEN005627
VP1039727
TEN004788
.75
208
3
TEN001131
VP1039721
TEN004682
15
460
3
TEN001131
TEN005494
TEN005803
.75
230
3
TEN001131
VP1039721
TEN004683
20
208
3
TEN005633
TEN005535
TEN004659
.75
460
3
TEN001131
VP1039720
TEN004684
20
230
3
TEN005633
TEN005535
TEN004786
1
208
3
TEN001131
VP1039722
TEN004685
20
460
3
TEN001131
TEN005495
TEN004790
1
230
3
TEN001131
VP1039722
TEN004688
25
230
3
TEN005633
VP1041424
TEN004659
1
460
3
TEN001131
VP1039720
TEN004999
25
460
3
TEN005627
VP1039727
TEN004789
1.5
208
3
TEN001131
VP1039723
TEN004999
30
460
3
TEN005627
VP1039727
ITEM
PART #
DESCRIPTION
QTY
3
TEN001132
TRANSFORMER,50VA
1
4
24CA5991
DIN RAIL
1
5
24CA5984
TERMINAL BLOCK
5
6
24CA5987
TERMINAL BLOCK,END STOP
2
7
24CA2897
FUSE 000.50A
2
8
24CA2898
FUSE 000.80A
1
9
24CA7881
GROUND LUG
2
10
24CA5985
TERMINAL BLOCK,END PLATE
1
11
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
