Section 5 – Parts List (cont.)
5.3 No Protection Circuit - 208V (25-30hp) & 230V (30hp)
PANEL PART #
HP
VOLTAGE
PHASE
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
TEN004687
25
208
3
TEN005632
VP1041428
TEN004687
30
208
3
TEN005632
VP1041428
TEN004690
30
230
3
TEN005632
VP1041428
ITEM
PART #
DESCRIPTION
QTY
3
TEN010159
TRANSFORMER,100VA
1
4
24CA5991
DIN RAIL
1
5
24CA5984
TERMINAL BLOCK
5
6
24CA5987
TERMINAL BLOCK,END STOP
2
7
24CA2897
FUSE 000.50A
2
8
24CA2898
FUSE 000.80A
1
9
24CA7881
GROUND LUG
2
10
24CA5985
TERMINAL BLOCK,END PLATE
1
11
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
