Champion Simplex - Page 29

Simplex Control Panel 29 CQF3475 v.02
Operation & Service August 06, 2019
Section 5 – Parts List (cont.)
5.4 No Protection Circuit - 575V
PANEL PART #
HP
VOLT
PHASE
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
TEN004665
1.5
575
3
TEN001131
VP1039721
TEN004665
2
575
3
TEN001131
VP1039721
TEN004673
3
575
3
TEN001131
VP1039722
TEN004675
5
575
3
TEN001131
VP1039723
TEN004678
7.5
575
3
TEN001131
TEN005493
TEN004680
10
575
3
TEN001131
TEN005496
TEN004680
15
575
3
TEN001131
TEN005496
TEN004686
20
575
3
TEN001131
TEN005494
TEN004689
25
575
3
TEN005627
VP1039727
TEN004689
30
575
3
TEN005627
VP1039727
ITEM
PART #
DESCRIPTION
QTY
3
TEN001132
TRANSFORMER,50VA
1
4
24CA5991
DIN RAIL
1
5
24CA5984
TERMINAL BLOCK
5
6
24CA5987
TERMINAL BLOCK,END STOP
2
7
24CA2896
FUSE 000.25A
2
8
24CA2898
FUSE 000.80A
1
9
24CA7881
GROUND LUG
2
10
24CA5985
TERMINAL BLOCK,END PLATE
1
11
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
