Champion Simplex - Page 33

Simplex Control Panel 33 CQF3475 v.02
Operation & Service August 06, 2019
Section 5 – Parts List (cont.)
5.6 With Protection Circuit - 208V, 230V, & 460V
PANEL
PART #
HP
VOLT
PH
ITEM 1
ITEM 2
PANEL
PART #
HP
VOLT
PH
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
CONTACTOR
OVERLOAD
TEN004899
.5
208
1
TEN001131
VP1039722
TEN004920
1.5
230
3
TEN001131
VP1039723
TEN004900
.5
230
1
TEN001131
VP1039721
TEN004921
1.5
460
3
TEN001131
VP1039721
TEN004905
.75
208
1
TEN001131
VP1039723
TEN004926
2
208
3
TEN001131
TEN005493
TEN004906
.75
230
1
TEN001131
VP1039722
TEN004920
2
230
3
TEN001131
VP1039723
TEN004905
1
208
1
TEN001131
VP1039723
TEN004928
2
460
3
TEN001131
VP1039722
TEN004912
1
230
1
TEN001131
VP1039723
TEN004926
3
208
3
TEN001131
TEN005493
TEN004917
1.5
208
1
TEN001131
TEN005493
TEN004908
3
230
3
TEN001131
TEN005493
TEN004918
1.5
230
1
TEN001131
TEN005493
TEN004910
3
460
3
TEN001131
VP1039723
TEN004924
2
208
1
TEN001131
TEN005496
TEN004915
5
208
3
TEN001131
TEN005496
TEN004925
2
230
1
TEN001131
TEN005496
TEN004927
5
230
3
TEN001131
TEN005496
TEN004931
3
208
1
TEN001131
TEN005494
TEN004929
5
460
3
TEN001131
TEN005493
TEN004932
3
230
1
TEN001131
TEN005494
TEN004935
7.5
208
3
TEN001131
TEN005494
TEN004931
5
208
1
TEN001131
TEN005494
TEN004936
7.5
230
3
TEN001131
TEN005494
TEN004932
5
230
1
TEN001131
TEN005494
TEN004929
7.5
460
3
TEN001131
TEN005493
TEN004933
7.5
208
1
TEN005627
VP1039727
TEN004938
10
208
3
TEN005627
VP1039727
TEN004934
7.5
230
1
TEN005627
VP1039727
TEN004939
10
230
3
TEN005627
VP1039727
TEN004901
.5
208
3
TEN001131
VP1039721
TEN004940
10
460
3
TEN001131
TEN005496
TEN004902
.5
230
3
TEN001131
VP1039720
TEN004942
15
208
3
TEN005627
TEN005535
TEN004903
.5
460
3
TEN001131
VP1039720
TEN004939
15
230
3
TEN005627
VP1039727
TEN004907
.75
208
3
TEN001131
VP1039721
TEN004943
15
460
3
TEN001131
TEN005494
TEN005835
.75
230
3
TEN001131
VP1039721
TEN004944
20
208
3
TEN005633
TEN005535
TEN004909
.75
460
3
TEN001131
VP1039720
TEN004945
20
230
3
TEN005633
TEN005535
TEN004913
1
208
3
TEN001131
VP1039722
TEN004946
20
460
3
TEN001131
TEN005495
TEN004914
1
230
3
TEN001131
VP1039722
TEN004949
25
230
3
TEN005633
VP1041424
TEN004909
1
460
3
TEN001131
VP1039720
TEN005000
25
460
3
TEN005627
VP1039727
TEN004919
1.5
208
3
TEN001131
VP1039723
TEN005000
30
460
3
TEN005627
VP1039727
ITEM
PART #
DESCRIPTION
QTY
3
TEN001132
TRANSFORMER,50VA
1
4
24CA5991
DIN RAIL
1
5
24CA5984
TERMINAL BLOCK
8
6
24CA5987
TERMINAL BLOCK,END STOP
2
7
TEN005628
RELAY
1
8
TEN001613
RELAY SOCKET
1
9
TEN001611
PUSHBUTTON, RESET (NOT SHOWN)
1
10
24CA2897
FUSE 000.50A
2
11
24CA2898
FUSE 000.80A
1
12
24CA7881
GROUND LUG
2
13
24CA5985
TERMINAL BLOCK,END PLATE
1
14
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
MCGUIRE AIR COMPRESSORS INC
1-888-229-9999
MCGUIRE AIR COMPRESSORS INC
1-888-229-9999
