Champion Simplex - Page 37

Simplex Control Panel 37 CQF3475 v.02
Operation & Service August 06, 2019
Section 5 – Parts List (cont.)
5.8 With Protection Circuit - 575V
PANEL PART #
HP
VOLTAGE
PHASE
ITEM 1
ITEM 2
CONTACTOR
OVERLOAD
TEN004922
1.5
575
3
TEN001131
VP1039721
TEN004922
2
575
3
TEN001131
VP1039721
TEN004911
3
575
3
TEN001131
VP1039722
TEN004930
5
575
3
TEN001131
VP1039723
TEN004937
7.5
575
3
TEN001131
TEN005493
TEN004941
10
575
3
TEN001131
TEN005496
TEN004941
15
575
3
TEN001131
TEN005496
TEN004947
20
575
3
TEN001131
TEN005494
TEN004950
25
575
3
TEN005627
VP1039727
TEN004950
30
575
3
TEN005627
VP1039727
ITEM
PART #
DESCRIPTION
QTY
3
TEN001132
TRANSFORMER,50VA
1
4
24CA5991
DIN RAIL
1
5
24CA5984
TERMINAL BLOCK
8
6
24CA5987
TERMINAL BLOCK,END STOP
2
7
TEN005628
RELAY
1
8
TEN001613
RELAY SOCKET
1
9
TEN001611
PUSHBUTTON, RESET (NOT SHOWN)
1
10
24CA2896
FUSE 000.25A
2
11
24CA2898
FUSE 000.80A
1
12
24CA7881
GROUND LUG
2
13
24CA5985
TERMINAL BLOCK,END PLATE
1
14
24CA6985
PUSH BUTTON, RESET, OVERLOAD (NOT SHOWN)
1
Contactor coil replacement
PART #
AMP RATING
CONTACTOR TYPE
VP1039975
15-40
DP
VP1039976
50
DP
VP1064513
65
IEC
VP1064516
80-95
IEC
