Name No. Name
1 Sewage tank cover 9 Squeegee lifting handle
2 Brush plate 10 Brush plate lift pedal
3 Tire 11 Sewage discharging pipe
4 Universal wheel 12 Squeegee
5 Anti-collision wheel 13 Clean water inlet
6 Controlling panel 14 Suction motor
7 Handrail 15 Sewage inlet
8 Sewage discharging pipe
1.3 Controlling panel and buttons
① Switch button ③ Suction motor button
② Brush plate button ④ Voltmeter
