Chapin 9008A - Replacement Parts

REPLACEMENT PARTS
REF NO. PART NO. QTY DESCRIPTION
1 6-9071 1 Gear Box Assembly
2 6-9040 1 Drive Shaft w/2 bearings
3 6-9083 1 Baffle System
4 6-9073 1 Bail Assembly
5 6-9096-1 1 Hardware Blister with auger
6 6-9061 1 Impeller
7 6-9020 1 Wheels w/hardware & instructions
8 6-9050 1 Rear Baffle
9 6-9001 1 Grate
Chapin Spreader Operator’s Manual - English
4E
5
Note: Not all components shown in
kit will be needed for your model
7
8
9
1
2
4
3
6
