Char-Broil 150 - Grill Assembly: Lid Components; Installing the Lid Air Vent; Attaching the Lid Handle

Align the center hole in the Lid Air Vent with the hole in the lid. Insert one
M5 x 8 screw with M5 flat washer through center hole and then install M5
lock washer and M5 nut. Be careful not to over tighten nut to allow proper
vent operation.
1
Medium Nut M5 - 1 piece
2
Align the holes in the Lid handle with the holes in the lid. Insert 2 M6 x 12
screws, 2 M6 flat washers and tighten.
Screw M6 x 12 - 2 pieces
Washer Head Screw M5 x 8 - 1 piece
9
ASSEMBLY
Lock Washer M5 - 1 piece
Flat Washer M5 - 1 piece
Flat Washer M6 - 2 piece
