A 1 TOP LID
B 1 HANDLE F/TOP LID
C 1 LOGO PLATE
RUBBER BUMPER, RECTANGLE, F/TOP
D 2
LID
E 1 FIREBOX
F 2 COOKING GRATE
G 1 WARMING RACK
FLAME CARRYOVER TUBE W/COTTER
H 1
PIN
I 2 MAIN BURNER, F/FIREBOX
J 2 FLAME TAMER
K 2 ELECTRODE, F/MAIN BURNER, 600MM
WIRE
L 2 SIDE SHELF, FIXED
M 1 LEFT SIDE SHELF, FOLDING
N 1 RIGHT SIDE SHELF, FOLDING
O 1 FASCIA, F/LEFT SIDE SHELF
P 1 FASCIA, F/RIGHT SIDE SHELF
Q 1 MAIN CONTROL PANEL
R 2 TEMPERATURE GAUGE, UFC MOUNTED
S 1 HOSE VALVE REGULATOR ASSY
T 1 MATCH HOLDER
U 2 BEZEL, F/CONTROL KNOB
V 2 CONTROL KNOB
W 1 CART UPPER BACK PANEL
X 1 LEFT RAIL, F/GREASE TRAY
Y 1 RIGHT RAIL, F/GREASE TRAY
Z 1 GREASE TRAY
AA 1 FRONT DOOR BRACE
BB 1 ELECTRONIC IGNITION MODULE
CC 1 BUTTON, F/ELECTRONIC IGNITION
MODULE
DD 1 IGNITER SWITCH MODULE
EE 1 DOOR, NO HANDLE
FF 1 DOOR HANDLE
GG 1 CART LEFT SIDE PANEL
HH 1 CART RIGHT SIDE PANEL
II 1 BOTTOM SHELF
JJ 1 TANK SCREW, F/BOTTOM SHELF
KK 2 CASTER, LOCKING
LL 2 CASTER, FIXED
MM 1 HARDWARE F/TOP LID ASSEMBLY
NN 2 RUBBER BUMPER, LID
NOT Pictured
_i n
... 1 DOOR MAGNET
... 1 CASTER PIN
... 1 HARDWARE PACK
... 1 ASSEMBLY MANUAL, ENGLISH
... 1 CLEANING TOOL
