Char-Broil Commercial T-22D

Assembly instructions © 2011

PRODUCT GUIDE

MODEL 463243812

© 2011 Char-Broil, LLC Columbus, GA 31902

Printed in China

Serial Number

Date Purchased

IMPORTANT: Fill out the product record information below.

See rating label on grill for serial number.

For support and to register your

grill, please visit us at

www.charbroil.com

If you have questions or need

assistance during assembly,

please call 1-888-430-7870.

06/13/11 • G350-001-070801

Table of Contents

Questions and Answers:

T
Thomas JohnsonJul 29, 2025
What to do if Char-Broil Grill has a sudden drop in gas flow or low flame?
- C
  christopherwilliamsJul 29, 2025
  A sudden drop in gas flow or low flame in your Char-Broil Grill might happen because you are out of gas, the excess flow valve has tripped, or there's a vapor lock at the coupling nut/LP cylinder connection. First, check the gas level in your LP cylinder. If that's not the issue, turn off the knobs, wait 30 seconds, and light the grill. If the flames are still low, turn off the knobs and LP cylinder valve, disconnect the regulator, reconnect it, and perform a leak test. Then, turn on the LP cylinder valve, wait 30 seconds, and light the grill. If it's a vapor lock, turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
A
Ann HebertAug 2, 2025
How to fix Char-Broil Grill when one burner does not light from other burners?
- Q
  qporterAug 2, 2025
  If one burner on your Char-Broil Grill does not light from the other burners, it could be due to grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush.
B
bradytimothyAug 7, 2025
How to stop Char-Broil Grill flare ups?
- M
  Maxwell OrrAug 7, 2025
  Flare-ups on your Char-Broil Grill can occur due to grease buildup, excessive fat in the meat, or excessive cooking temperature. To resolve this, clean the burners and the inside of the grill/firebox. Trim fat from the meat before grilling. Also, adjust the cooking temperature accordingly by lowering it.
K
Katherine WilliamsAug 11, 2025
Why do the flames blow out on my Char-Broil Grill?
- J
  Jeffery JohnsonAug 11, 2025
  Flames blowing out on your Char-Broil Grill can be caused by high or gusting winds, or low LP gas, or tripped excess flow valve. Turn the front of the grill to face the wind or increase the flame height. If that doesn't work, refill the LP cylinder. You can also refer to the “Sudden drop in gas flow” solution.
C
Christian HammondAug 15, 2025
What to do about a persistent grease fire in Char-Broil Grill?
- K
  Kara KingAug 15, 2025
  If you have a persistent grease fire in your Char-Broil Grill, turn the knobs to the OFF position and turn the gas off at the LP cylinder. Leave the lid in position and let the fire burn out. After the grill cools, remove and clean all parts, because the grease is trapped by food buildup around burner system.
N
Nicholas SmithAug 19, 2025
What causes flashback fire in burner tubes of Char-Broil Grill?
- S
  Sarah KellyAug 19, 2025
  A flashback, or fire in the burner tubes, of your Char-Broil Grill indicates that the burner and/or burner tubes are blocked. Turn the knobs to the OFF position and clean the burner and/or burner tubes. See burner cleaning section of Use and Care.
R
Ricky YangAug 25, 2025
How to fix Char-Broil Grill timer when the green light does not flash?
- J
  James ParksAug 25, 2025
  If the timer on your Char-Broil Grill isn't working and the green light doesn't flash, it could be due to a dead battery, incorrectly installed batteries, or the knob position not starting the clean cycle. Replace the batteries. Ensure the batteries are installed correctly. Push the knob in to start the clean cycle (the green LED should begin to flash).

Char-Broil 463243812 Specifications

General

Brand	Char-Broil
Model	463243812
Category	Grill
Language	English

Summary

Safety Guidelines

Understanding Safety Symbols

Explains DANGER, WARNING, and CAUTION symbols used in the manual.

Installer and Consumer Roles

Defines responsibilities for installers and end-users of the grill.

Installation Safety

California Proposition 65 Warning

Alerts users to chemicals in the product and potential reproductive harm.

General Installation Precautions

Outlines essential safety steps before and during grill installation.

Use and Care Instructions

LP Cylinder Handling and Storage

Details safe practices for storing, transporting, and handling LP cylinders.

LP Cylinder Filling and Properties

Covers LP gas characteristics, filling procedures, and safety precautions.

LP Cylinder Exchange and Leak Testing

Guides on exchanging cylinders and performing leak tests for safety.

Connecting the Regulator to the LP Cylinder

Step-by-step instructions for securely connecting the gas regulator to the cylinder.

Leak Testing Valves, Hose, and Regulator

Procedures for testing gas connections for leaks using a soap solution.

Grill Operation and Safety

Safe Grill Usage and Placement

Provides essential safety rules for operating the grill in various environments.

Ignitor Lighting Procedure

Step-by-step guide for safely lighting the grill burners using the ignitor.

Burner Flame Checks and Grill Shutdown

Instructions for checking burner flames and safely turning off the grill.

General Grill Cleaning and Maintenance

Guidance on cleaning various grill components and surfaces.

Maintenance and Storage

Spider Alert and Burner Tube Cleaning

Addresses issues caused by spiders/insects and cleaning burner assemblies.

Grill Storage Procedures

Safe methods for storing the grill when not in use, including LP cylinder handling.

Limited Warranty Policy

Warranty Coverage and Limitations

Details the scope, duration, and exclusions of the product warranty.

Parts Identification

Parts List and Descriptions

Lists all grill components with corresponding keys and quantities.

Parts Diagram

Visual Parts Breakdown

Illustrates the location and labeling of all grill parts for assembly.

Assembly Instructions

Caster and Bottom Shelf Installation

Guides on attaching casters and the bottom shelf to the grill cart.

Side Panel Attachment to Bottom Shelf

Instructions for attaching the left and right side panels to the bottom shelf.

Upper Back Panel Attachment

Details securing the upper back panel to the grill cart structure.

Temperature Gauge and Side Shelf Fascie Installation

Steps for installing the temperature gauge and side shelf fascia.

Foldable Side Shelf Bracket Installation

How to attach and deploy the foldable side shelf brackets.

Side Shelf and Control Panel Attachment

Securing side shelves and fascia to the grill's main body.

Front Brace and Grease Tray Rail Installation

Installing the front brace and the rails for the grease tray.

Ignition Module and Door Installation

Connecting the electronic ignition module and attaching the grill door.

Flame Tamers, Grates, and Warming Rack Installation

Placing flame tamers, cooking grates, and warming rack.

Grease Tray and Ignitor Battery Installation

Installing the grease tray and the battery for the electronic ignitor.

LP Cylinder Securing and Final Assembly

Instructions for installing and securing the LP cylinder.

Troubleshooting

Gas Leak and Fire Safety Issues

Addresses emergencies related to gas leaks, fires, and flame issues.

Burner Ignition and Gas Flow Problems

Diagnoses and resolves issues with burners failing to light or having low gas flow.

Flame Control and Grease Fire Troubleshooting

Solutions for flame blowouts, flare-ups, grease fires, and flashback issues.

Electronic Ignition System Diagnosis

Detailed guide for troubleshooting electronic ignition system faults.

Product Registration

Warranty Registration Process

Instructions for registering the product to activate warranty coverage.
