Char-Broil C ommercial C -46DL

Assembly instructions © 2011

PRODUCT GUIDE

MODEL 463244012

© 2011 Char-Broil, LLC Columbus, GA 31902

Printed in China

Serial Number

Date Purchased

IMPORTANT: Fill out the product record information below.

See rating label on grill for serial number.

For support and to register your

grill, please visit us at

www.charbroil.com

If you have questions or need

assistance during assembly,

please call 1-800-241-7548.

06/17/11 • G515-001-180801

Table of Contents

Questions and Answers:

R
Ryan PerryJul 30, 2025
What to do if the Char-Broil 463244012 Grill burner won't light using the ignitor?
- C
  Clayton HarrisJul 31, 2025
  If the burners on your Char-Broil Grill won't light using the ignitor, start by replacing the battery with a new alkaline one. If that doesn't work, check the wires connected to the ignitor and electrode to ensure they are properly connected. If the wires are loose or disconnected, reconnect them or replace the electrode/wire assembly. Also, inspect the electrode for cracks or damage. If you notice any damage or the electrode 'sparks at the crack,' replace the electrode.
A
Amy HerringAug 6, 2025
Why won't my Char-Broil Grill burner light with the ignitor?
- J
  Jose GreenAug 6, 2025
  If the burner(s) on your Char-Broil grill won't light using the ignitor, there might be an obstruction in the burner tubes caused by spider webs or other debris. Make sure that you clean burner tubes. Also, make sure the valves are positioned inside of burner tubes. If there's still no gas flow, ensure your LP cylinder isn't empty. If the cylinder isn't empty, refer to 'Sudden drop in gas flow'.
W
William DavidsonAug 12, 2025
How to fix a Char-Broil 463244012 when the burner won't light with the ignitor?
- K
  Kendra SchmidtAug 12, 2025
  If the burner(s) on your Char-Broil grill won't light using the ignitor, and you suspect a vapor lock, turn off the control knobs and disconnect the coupling nut from the LP cylinder. Then, reconnect the coupling nut to the LP cylinder and try lighting the grill again. Also, make sure the coupling nut and LP cylinder valve are fully connected by hand-tightening the coupling nut an additional one-half to three-quarters of a turn until you reach a solid stop. Avoid using tools to tighten it.
V
vacostaAug 18, 2025
How to troubleshoot Char-Broil 463244012 ignitor problems?
- W
  Wayne HarringtonAug 18, 2025
  If the burner(s) on your Char-Broil grill won't light using the ignitor, ensure you are attempting to light the correct burner following the instructions on the control panel and in the Use and Care section. Also, make sure the tip of the electrode is pointing towards the gas port opening on the burner, positioned approximately 1/8” to 1/4” away. Adjust the position if necessary.
S
Sarah HicksAug 25, 2025
What to do if Char-Broil Grill ignitor is sparking?
- K
  Kenneth OrtizAug 25, 2025
  If the burner(s) on your Char-Broil grill won't light using the ignitor, the wire and/or electrode may be covered with cooking residue. To resolve this, clean the wire and/or electrode using rubbing alcohol and a clean swab. Also, inspect the wires between the ignitor and electrode for any shorting (sparking). If shorting is observed, replace the ignitor wire/electrode assembly.

Char-Broil 463244012 Specifications

General

Brand	Char-Broil
Model	463244012
Type	Gas Grill
Fuel Type	Propane
Burner Material	Stainless Steel
Material	Porcelain-Coated Steel
Ignition	Electronic

Summary

Installation Safety Precautions

Grilling Guide: Getting Started

First Time Use

Grilling Guide: Grilling 101

Direct Cooking Method

Indirect Cooking Method

Food Safety Essentials

Four essential steps for safe food handling and preparation.

Use and Care: LP Cylinder Handling

LP Cylinder Requirements

Requirements and specifications for the LP gas cylinder.

LP Gas Properties and Safety

Properties and safety information about LP gas.

LP Cylinder Filling Procedures

Proper procedures and safety for filling LP cylinders.

Use and Care: Cylinder Exchange and Leak Testing

LP Cylinder Exchange Options

LP Cylinder Leak Testing Procedure

Steps to perform a leak test on the LP cylinder and connections.

Connecting the Regulator to the LP Cylinder

Detailed instructions for connecting the regulator to the LP cylinder valve.

Use and Care: Leak Testing Gas Connections

Use and Care: Safe Operation and Lighting

Safe Grill Operation Rules

Critical safety rules for operating the grill and preventing injury.

Ignitor Lighting Guide

Step-by-step guide to lighting the grill using the ignitor.

Use and Care: Burner Cleaning and Storage

Spider Alert and Burner Cleaning

How to address spider blockages and clean burner assemblies.

Limited Warranty

Scope of Coverage

Details the parts covered and their warranty periods.

Exclusions from Warranty

Warranty Disclaimers and Limitations

Parts List

Assembly Instructions

Troubleshooting
