To Next PageTo Next PageHow to stop flare ups on my Char-Broil 463247512?
Flare-ups on your Char-Broil Grill can occur due to a few reasons. First, grease buildup can cause flare-ups, so clean the burners and inside of the grill/firebox. Second, excessive fat in the meat can be a culprit; trim the fat before grilling. Finally, excessive cooking temperature might be the reason, adjust the temperature accordingly by lowering it.
What to do if my Char-Broil 463247512 Grill has a sudden drop in gas flow?
A sudden drop in gas flow or low flame in your Char-Broil Grill could be due to several reasons: * You might be out of gas, so check the LP cylinder. * The excess flow valve may have tripped; turn off the knobs, wait 30 seconds, and light the grill. If flames are still low, turn off knobs and the LP cylinder valve, disconnect the regulator, reconnect it, leak-test, turn on the LP cylinder valve, wait 30 seconds, and then light the grill. * A vapor lock might have occurred at the coupling nut/LP cylinder connection; turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
Why do the flames keep blowing out on my Char-Broil 463247512?
If the flames on your Char-Broil Grill keep blowing out, it could be due to high or gusting winds; turn the front of the grill to face the wind or increase the flame height. Alternatively, you might be low on LP gas, so refill the LP cylinder. It's also possible that the excess flow valve has tripped; refer to the “Sudden drop in gas flow” section for guidance.
Why no sparks when I press the ignition button on my Char-Broil Grill?
If no sparks appear at any electrodes when the Electronic Ignition Button is pressed and no noise can be heard from spark module on your Char-Broil Grill, it could be due to several reasons: * The battery might not be installed properly; install the battery, ensuring that the “+” and “–” connectors are oriented correctly, with the “+” end up and “–” end down. * The battery might be dead; replace it with a new alkaline battery. * The button assembly might not be installed properly; unscrew the button cap assembly and reinstall it, making sure the threads are aligned and engaged fully. * The spark module might be faulty; replace the spark module assembly.
Why are the sparks weak on my Char-Broil Grill?
If sparks are present but not at all electrodes and/or not at full strength on your Char-Broil Grill, it could be due to several reasons: * Output lead connections might not be connected; remove and reconnect all output connections at the module and electrodes. * Arcing to the grill away from the burner(s) might be occurring; if possible, observe the grill in a dark location, operate the ignition system, and look for arcing between the output wires and the grill frame. * The battery might be weak; replace the battery with a new alkaline battery. * The electrodes might be wet; use a paper towel to remove moisture. * The electrodes might be cracked or broken, causing sparks at the crack; replace cracked or broken electrodes.
What to do if one burner doesn't light from others on Char-Broil 463247512?
If one burner does not light from other burners on your Char-Broil Grill, it's likely due to grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush to resolve this.
How to handle a persistent grease fire in Char-Broil 463247512?
If you have a persistent grease fire in your Char-Broil Grill, turn the knobs to OFF and turn off the gas at the LP cylinder. Leave the lid in position and let the fire burn out. After the grill cools, remove and clean all parts, as the grease might be trapped by food buildup around the burner system.
What causes flashback in burner tubes of Char-Broil 463247512 Grill?
A flashback (fire in burner tubes) in your Char-Broil Grill usually means the burner and/or burner tubes are blocked. To resolve this, turn the knobs to OFF and clean the burner and/or burner tubes. Refer to the burner cleaning section of the Use and Care guide.
What if I hear noise but no sparks on my Char-Broil 463247512?
If you hear noise from the spark module but no sparks appear at any electrodes when the Electronic Ignition Button is pressed on your Char-Broil Grill, the output lead connections might not be connected. Remove and reconnect all output connections at the module and electrodes.
Why can't I fill my Char-Broil 463247512 LP cylinder?
If you are unable to fill your LP cylinder, it might be because some dealers have older fill nozzles with worn threads. These worn nozzles might not have enough “bite” to engage the valve. Try a second LP dealer.
General| Brand | Char-Broil |
|---|---|
| Model | 463247512 |
| Category | Grill |
| Language | English |
Indicates an imminent hazard leading to death or serious injury if not avoided.
Indicates a potentially hazardous situation leading to death or serious injury if not avoided.
Indicates a potentially hazardous situation leading to minor or moderate injury if not avoided.
Use grill with LP gas and supplied regulator; purchase kit for natural gas.
Never store spare cylinders indoors; avoid overfilling for safety.
Proper removal, transport, and storage procedures for LP cylinders.
Specifications for LP cylinders, including valve features like OPD.
Secure cylinder and ensure control knobs are off before connecting.
Turn LP cylinder valve clockwise to OFF and remove protective cap.
Insert regulator nipple into valve and hand-tighten coupling nut.
Ensure regulator is tight, open cylinder valve, and apply soap solution.
Observe for bubbles indicating leaks; close valve and retighten if found.
Keep area clear, use in ventilated space, avoid lid closed lighting.
Avoid foil on grates, maintain 3ft wall and 10ft object clearance.
Turn controls off, turn on gas, open lid, push/turn knob to HI.
Addresses leaks from hoses, cylinders, valves, and connections.
Covers fires from control panels and grease buildup causing excessive flames.
Covers issues with electronic ignition and match lighting.
Addresses low flame, blowouts, flare-ups, grease fires, and flashbacks.
Diagnosing issues when no spark or noise is heard from the module.
Troubleshooting when noise is heard but no spark appears at electrodes.
Addressing situations with sparks present but not at all electrodes or full strength.
