Char-Broil Commercial T-36D
Assembly instructions © 2011
PRODUCT GUIDE
MODEL 463247412
© 2011 Char-Broil, LLC Columbus, GA 31902
Printed in China
Serial Number
Date Purchased
IMPORTANT: Fill out the product record information below.
See rating label on grill for serial number.
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-888-430-7870.
06/13/11 • G515-001-190801

Table of Contents

Questions and Answers

  • H
    Holly JenkinsAug 19, 2025
    Why is the flame so low on my Char-Broil Grill?
    • H
      Heidi PerkinsAug 19, 2025
      A sudden drop in gas flow or low flame on your Char-Broil Grill can happen if you're out of gas, so check the LP cylinder. It could also be that the excess flow valve tripped. To fix this, turn off the knobs, wait 30 seconds, and light the grill. If flames are still low, turn off the knobs and LP cylinder valve, disconnect the regulator, reconnect it, and leak-test. Then, turn on the LP cylinder valve, wait 30 seconds, and light the grill. Another cause can be vapor lock at the coupling nut/LP cylinder connection. To resolve this, turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
  • D
    Donna ConnerAug 21, 2025
    What to do if flames blow out on Char-Broil 463247412?
    • C
      Christina LaneAug 21, 2025
      If flames are blowing out on your Char-Broil Grill, it could be due to high or gusting winds; turn the front of the grill to face the wind or increase the flame height. Another cause is low LP gas, so refill the LP cylinder. Also, the excess flow valve might have tripped; in this case, refer to the troubleshooting steps for a sudden drop in gas flow.
  • J
    Julie LoweAug 23, 2025
    Why no spark on my Char-Broil 463247412 Grill?
    • S
      Sandra GarnerAug 25, 2025
      If no sparks appear at any electrodes when the Electronic Ignition Button is pressed on your Char-Broil Grill, and no noise can be heard from spark module, check the battery orientation. If that's not the issue, replace the battery with a new alkaline battery. Also, ensure the button assembly is installed properly by unscrewing the button cap assembly and reinstalling it, making sure the threads are aligned and engaged fully. If the problem persists, the spark module may be faulty and needs replacement.
  • M
    maryjensenAug 26, 2025
    Why can't I fill my Char-Broil 463247412 Grill LP cylinder?
    • C
      cevansAug 26, 2025
      If you're unable to fill your LP cylinder for your Char-Broil Grill, it might be because some dealers have older fill nozzles with worn threads. Try a second LP dealer.
  • D
    Diana Braun MDAug 28, 2025
    How to manually light my Char-Broil 463247412 Grill?
    • J
      jjacksonAug 28, 2025
      If your Char-Broil Grill burner(s) will not match light, use a long-stem match (fireplace match). You may also consult the “Match-Lighting” section of Use and Care guide.
  • J
    jacksonstephanieAug 30, 2025
    Why won't one burner light on my Char-Broil 463247412?
    • J
      Jennifer RuizAug 30, 2025
      If one burner does not light from other burner(s) on your Char-Broil Grill, it could be due to grease buildup or food particles in the end(s) of the carryover tube(s). To resolve this, clean the carry-over tube(s) with a wire brush.
  • B
    brownkevinSep 1, 2025
    How to stop flare ups on my Char-Broil Grill?
    • K
      Kathryn BowenSep 2, 2025
      Flare-ups on your Char-Broil Grill can be caused by grease buildup. To resolve this, clean the burners and the inside of the grill/firebox. Another cause can be excessive fat in the meat, so trim the fat before grilling. Also, excessive cooking temperature can cause flare-ups, so adjust the temperature accordingly by lowering it.
  • T
    Tony YangSep 4, 2025
    How to stop a grease fire in Char-Broil 463247412?
    • H
      Hannah MillsSep 4, 2025
      A persistent grease fire in your Char-Broil Grill is usually caused by grease trapped by food buildup around the burner system. To resolve this, turn the knobs to OFF, turn the gas off at the LP cylinder, and leave the lid in position to let the fire burn out. After the grill cools, remove and clean all parts.
  • E
    Eugene Dyer DDSSep 6, 2025
    What causes flashback in Char-Broil 463247412 Grill burner tubes?
    • M
      Monique MortonSep 6, 2025
      If you experience flashback (fire in burner tube(s)) with your Char-Broil Grill, it's likely because the burner and/or burner tubes are blocked. To fix this, turn the knobs to OFF and clean the burner and/or burner tubes. Refer to the burner cleaning section of the Use and Care guide for detailed instructions.
  • M
    Mitchell HarmonSep 8, 2025
    Why Char-Broil Grill timer doesn't work?
    • S
      Sarah ShermanSep 8, 2025
      If the timer on your Char-Broil grill isn't working (the green light doesn't flash), it might be due to a dead battery, so replace the batteries. Another possibility is that the batteries are installed incorrectly; make sure to install them correctly. It's also possible that the knob position did not start the Clean Cycle; push the knob in to start the clean cycle. (The green LED should begin to flash).

Summary

Safety Symbols and Definitions

Hazard Symbol Meanings

Explains DANGER, WARNING, and CAUTION symbols and their implications for user safety.

User Roles and Usage Guidelines

Defines installer/consumer responsibilities and specifies outdoor-only use.

Proposition 65 and Installation Safety

California Proposition 65 Warnings

States chemical warnings required by California law for product components.

Installation Safety Precautions

Key safety steps for installation, including electrical and ventilation requirements.

Component Cautions

Specific warnings for repair, pot size limits, and porcelain surface handling.

Use and Care - LP Cylinder Safety

LP Cylinder Storage and Handling

Essential safety guidelines for storing, transporting, and handling LP gas cylinders.

LP Gas Properties and Filling Procedures

Information on LP gas characteristics and safe cylinder filling practices.

Use and Care - LP Cylinder Exchange & Connection

LP Cylinder Exchange and Leak Testing

Procedures for exchanging an LP cylinder and performing a crucial leak test.

Connecting the LP Regulator to the Cylinder

Step-by-step instructions for correctly attaching the gas regulator to the LP cylinder valve.

Use and Care - Leak Testing & Warnings

Gas System Leak Testing

Detailed instructions for leak testing valves, hoses, and the regulator for gas leaks.

Important Operational Warnings

Critical warnings regarding tool use, outdoor appliance placement, and RV/boat installation.

Use and Care - General Safety & Operation

General Grill Safety and Apartment Use

Key safety rules for grill operation, clearances, and specific advice for apartment dwellers.

Ignitor Lighting Procedure

Step-by-step guide for lighting the grill burners using the electronic ignitor.

Use and Care - Operation & Maintenance

Match-Lighting and Flame Checks

Instructions for alternative match-lighting and performing burner flame checks.

Operation Checks and General Cleaning

Maintenance checks for ignitors, valves, hoses, and general grill cleaning procedures.

Spider Alert and Burner Maintenance

Spider Alert and Venturi Tube Cleaning

Addresses issues caused by spiders/insects in venturi tubes and cleaning procedures.

Grill Storage and Burner Assembly Care

Guidelines for storing the grill and cleaning the burner assembly.

Limited Warranty Details

Warranty Coverage and Exclusions

Outlines what the warranty covers, for how long, and what is specifically excluded.

Remedies, Implied Warranties, and Limitations

Explains available remedies, legal disclaimers, and warranty limitations.

Parts List and Identification

Grill Component Parts List

Comprehensive list of all parts with keys, descriptions, and quantities.

Not Pictured Components

Lists additional parts not visually depicted in the main parts list.

Parts Diagram

Visual Component Layout and Labeling

Illustrates the physical arrangement and identification labels for all grill parts.

Grill Assembly Instructions

Cart Base and Caster Installation

Step-by-step guide for attaching casters to the bottom shelf and side panels.

Lower Back Panel and Grill Head Mounting

Lower Back Panel and Grill Head Mounting

Attaching the lower back panel and carefully positioning the main grill head onto the cart.

Upper Back Panel and Right Side Shelf Attachment

Upper Back Panel and Right Side Shelf Attachment

Securing the upper back panel and attaching the right side shelf to the firebox brackets.

Left Side Shelf and Control Panel Assembly

Left Side Shelf and Control Panel Assembly

Installing the left side shelf, fascia, and connecting it to the main control panel area.

Sideburner Valve and Burner Installation

Sideburner Valve and Burner Installation

Procedures for mounting the sideburner valve bracket and inserting the sideburner.

Sideburner Ignition Wire and Front Brace

Sideburner Ignition Wire and Front Brace

Connecting the sideburner ignitor wire and securely mounting the front brace.

Internal Shields and Ignition Module Installation

Internal Shields and Ignition Module Installation

Installing tank heat shields, grease tray rails, and the electronic ignition module.

Door Hinge Installation and Flame Tamers

Door Hinge Installation and Flame Tamers

Attaching the grill doors via hinges and placing the flame tamers.

Grates, Warming Rack, and Grease Tray

Grates, Warming Rack, and Grease Tray

Placing cooking grates, warming rack, and installing the grease tray for proper function.

Ignition Battery and LP Cylinder Connection

Ignition Battery and LP Cylinder Connection

Installing the ignitor battery and correctly connecting the LP cylinder and regulator.

Troubleshooting Common Grill Problems

Emergency Procedures for Gas Leaks and Fires

Critical steps to take in case of gas leaks, fires, or burner tube issues.

Burner Ignition and Gas Flow Issues

Diagnosing and resolving problems related to igniting burners and inconsistent gas flow.

Flame Stability and Grease Fire Resolution

Flame Stability and Grease Fire Resolution

Addressing issues like flames blowing out, flare-ups, grease fires, and LP cylinder filling.

Single Burner and Auto-Clean Issues

Troubleshooting for one burner not lighting and the AUTO-CLEAN™ timer functionality.

Electronic Ignition System Troubleshooting

Electronic Ignition System Troubleshooting

Comprehensive guide to diagnosing and fixing electronic ignition system faults.

Product Registration and Warranty Service

Online Registration and Warranty Requirements

Instructions for online product registration and essential requirements for warranty service.

Customer and Product Information Fields

Details on personal information and product specifics needed for registration.
