Char-Broil 463270614 Performance T-22D User Manual

17
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
PARTS LIST
NOT Pictured
… 1 DOOR MAGNET
… 1 CASTER PIN
… 1 HARDWARE PACK
… 1
ASSEMBLY MANUAL, ENGLISH, FRENCH,
SPANISH
… 1 CLEANING TOOL
Key Qty Description
1 1 TOP LID
2 1 HANDLE F/ TOP LID
3 1 LOGO PLATE
4 2 RUBBER BUMPER, RECTANGLE, F/ TOP LID
5 1 FIREBOX
6 2 COOKING GRATE
7 1 WARMING RACK
8 1 FLAME CARRYOVER TUBE W/ COTTER PIN
9 2 MAIN BURNER, F/ FIREBOX
10 2 HEAT TENT
11 2 ELECTRODE, F/ MAIN BURNER, 600MM WIRE
12 2 SIDE SHELF, FIXED
13 1 LEFT SIDE SHELF, FOLDING
14 1 RIGHT SIDE SHELF, FOLDING
15 1 FASCIA, F/ LEFT SIDE SHELF
16 1 FASCIA, F/ RIGHT SIDE SHELF
17 1 MAIN CONTROL PANEL
18 2 TEMPERATURE GAUGE, UFC MOUNTED
19 1 HOSE VALVE REGULATOR ASSY
20 1 MATCH HOLDER
21 2 BEZEL, F/ CONTROL KNOB
22 2 CONTROL KNOB
23 1 CART UPPER BACK PANEL
24 1 LEFT RAIL, F/ GREASE TRAY
25 1 RIGHT RAIL, F/ GREASE TRAY
26 1 GREASE TRAY
27 1 FRONT DOOR BRACE
28 1 ELECTRONIC IGNITION MODULE
29 1 BUTTON, F/ ELECTRONIC IGNITION MODULE
30 1 IGNITER SWITCH MODULE
31 1 DOOR, NO HANDLE
32 1 DOOR HANDLE
33 1 CART LEFT SIDE PANEL
34 1 CART RIGHT SIDE PANEL
35 1 BOTTOM SHELF
36 1 TANK SCREW, F/ BOTTOM SHELF
37 2 CASTER, LOCKING
38 2 CASTER, FIXED
39 1 HARDWARE F/ TOP LID ASSEMBLY
40 2 RUBBER BUMPER, LID
