PAGE 4
5
6
Remove / replace HEAT TENT.
HEAT TENT
Remove / replace all burner HITCH PINS, CARRYOVER TUBES and BURNER BRACES. Lift back end of burner up to disengage from
valve and rest on back wall of firebox.
VERY IMPORTANT: Burner tubes must reengage valve openings when replace burners.
CARRYOVER
TUBE
HITCH PIN
Correct burner-to-valve engagement
1ST
2ND
BURNER
BURNER BRACE
To Next Page
