PAGE 5
SIDEBURNER GRATE
7
Remove / replace SIDEBURNER GRATE.
8
Disconnect / connect side burner and main burner ELECTRODE WIRES.
Remove / replace side burner VENTURI CLIP and WING SCREW.
Remove / replace SIDE BURNER.
SIDEBURNER
VENTURI CLIP
SIDE BURNER ELEC-
TRODE WIRE
MAIN BURNER
ELECTRODE WIRE
