Char-Broil 463341021 - Firebox Shelf and Fasteners Replacement

PAGE 7
11
Remove / replace SCREWS and WASHERS inside firebox.
Remove / replace bottom two shelf mounting screws.
Loosen / tighten two screws as shown.
Lift shelf up and out to remove shelf. Both sides.
2ND
3RD
1ST
Loosen/ TightenLoosen/ Tighten
Remove / ReplaceRemove / Replace
