PAGE 8
12
Remove / replace CONTROL PANEL.
CONTROL PANEL
13
Remove / replace LED WIRE HARNESS.
REVERSE THE STEPS TO ASSEMBLE THE GRILL.
NOTE: READ THE USE AND CARE GUIDE IN INSTRUCTION MANUAL PRIOR TO LIGHTING THE GRILL.
LED WIRE HARNESS
