Char-Broil T-22D User Manual

PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
11
Key Qty Description
A 1 TOP LID
B 2 BEZEL, F/ LID HANDLE
C 1 HANDLE F/ TOP LID
D 1 LOGO PLATE, TEMP GAUGE
E 2 RUBBER BUMPER, ROUND, W/ HARDWARE, F/
TOP LID
F 2 RUBBER BUMPER, LID
G 1 FIREBOX
H 2 COOKING GRATE
I 1 WARMING RACK
J 2 MAIN BURNER, F/ FIREBOX
K 2 ELECTRODE W/ WIRE/COLLECTOR, F/ MAIN
BURNER
L 1 CARRY OVER, F/ MAIN BURNER
M 2 SIDE SHELF, FIXED
N 1 LEFT SIDE SHELF, FOLDING
O 1 RIGHT SIDE SHELF, FOLDING
P 1 FASCIA, F/ LEFT SIDE SHELF
Q 1 FASCIA, F/ RIGHT SIDE SHELF
R 1 MAIN CONTROL PANEL
S 1 HOSE VALVE REGULATOR ASSY
T 1 MATCH HOLDER
U 2 BEZEL, F/ CONTROL KNOB
V 2 CONTROL KNOB
W 1 CART UPPER BACK PANEL
X 1 HEAT SHIELD, F/ TANK
Y 1 FRONT DOOR BRACE
Z 1 ELECTRONIC IGNITION MODULE
AA 1 BUTTON, F/ ELECTRONIC IGNITION MODULE
BB 1 IGNITER SWITCH MODULE
CC 1 DOOR, NO HANDLE
DD 1 DOOR HANDLE
EE 1 CART LEFT SIDE PANEL
FF 1 CART RIGHT SIDE PANEL
GG 1 BOTTOM SHELF
HH 1 TANK SCREW, F/ BOTTOM SHELF
II 2 CASTER, LOCKING
JJ 2 CASTER, FIXED
KK 1 HARDWARE F/ TOP LID ASSEMBLY
LL 1 TROUGH, FIREBOX
Key Qty Description
… 1 DOOR MAGNET
… 1 CASTER PIN
… 1 HARDWARE PACK
… 1 ASSEMBLY MANUAL, ENGLISH
… 1 ASSEMBLY MANUAL, FRENCH
NOT Pictured
