page 9
HAIR COTTER PIN….3 PCS
CENTER HINGE PIN…1 PC
¼” LOCK WASHER…35 PCS
HINGE PINS………..2 PCS
¼-20 HEX NUT……..19 PCS
¼” FLAT WASHER…10 PCS
SCREW……………….3 PCS
¼-20x1/2” BOLT….... 43 PCS
¼-20x 1 ½” BOLT……8 PCS
Assembly: Requires 2 people. Get another person to help.
Tools Needed: Pliers, Phillips Head Screwdriver and a 7/16” Nut Driver.
NOTE: Do Not tighten any bolts unless instructed to do so. Tightening too soon may prohibit
parts from fitting together. All Hex Nuts should be on the inside of the grill unless stated
otherwise. Unpack all contents in a well cleared and padded area.
Estimated Assembly Time: 45 minutes
STOP! Do Not Return to Store. If you are missing parts or need assistance please email us at
info@patioworld.nl or call 0031 (0)114 671493. Do not attempt assembly if you are missing
parts.
