OME3072 E.2 ™ & © Char-Griller / A&J Manufacturing 3
¼-20x 1 ½” BOLT………….…....2 PCS
¼-20x ½” BOLT….................. 37 PCS
2/5” FLAT WASHER……………...2 PCS
¼” FLAT WASHER………………...5 PCS
¼-20 HEX NUT…………….........10 PCS
¼” LOCK WASHER……………..33 PCS
HINGE PINS…………..................2 PCS
LARGE HAIR COTTER PIN……...2 PCS
SMALL HAIR COTTER PIN……...2 PCS
SCREW……………………….....…....3 PCS
#10-24 x 0.40” BOLT…...…......6 PCS
HUB CAP………………………………2 PCS
1/4-20 x 3 1/4” WING BOLT…..1 PC
¼-20x 3/4” BOLT………….…....2 PCS
Hardware: 551053
Assembly: Requires 2 people. Get another person to help.
Tools Needed: Pliers, Phillips Head Screwdriver and a 7/16” Nut Driver.
NOTE: Do Not tighten any bolts unless instructed to do so. Tightening too soon may
prohibit parts from fitting together. All Hex Nuts should be on the inside of the grill
unless stated otherwise. Unpack all contents in a well cleared and padded area.
STOP! Do Not Return to Store. If you are missing parts or need assistance please
email us at info@chargriller.com or call 912-638-4724. Do not attempt assembly if
you are missing parts.
