Step 8
Install the Catch Pan onto the bottom of the Grill Body by sliding the Catch Pan un-
derneath the Grill Body bottom. Making sure that the Brackets on the Catch Pan
rest on top of Slider Brackets. Slid the Catch Pan all the way till you can hang the
Catch Pan side bracket onto the Stopper Bracket.
Catch Pan
Slider Bracket
Stopper Bracket
Catch Pan
Side Bracket
Grease Cup
