-11-
SPECIFICATIONS
Model MS 3400 / MS 3400-1 (DP 2700)
Capacity 300 kg x 0.1 kg
Accuracy ±150g
Weight Unit kg / lb
Operating Temp. &
Humidity
+ 5°C ~ + 35°C
15% - 85% RH
Transport and Storage
Temperature & Humidity
- 20°C + 60°C
10% - 95% RH
LCD Display 1.0” LCD digital display
Dimension
Platform size: 310 x 310 mm
Column Height: 900mm
Key Functions
HOLD/BMI , UNIT/WEIGHT , ON/ZERO/OFF ,
TARE
Power Supply
12V- 15V adapter
1.5V AAA battery * 6
Optional Accessories HM201M height rod 60 ~ 205 cm / 6ft 9inch
1. Place the tare object (additional loads or clothes) onto the
tread platform.
2. Press [TARE] key after the weight stabilizes and stable sign
displays. Remove the tare object from the platform first, so
the display will return to zero for the second time weighing of
the gross weight.
3. Place the gross object/person to be weighed (Including the
tare object on the tread platform)
4. The weighing result is the Net weight of the item / person.
5. To delete the saved tare value, remove the tare object from
the tread platform and press [TARE] key.
CONNECTING AC ADAPTER
Plug in AC adapter or put in batteries as power source.
(For rechargeable version)
Please connect to AC adapter to charge your scale for at least 14 hours
before first use.
Fully charged rechargeable batteries could provide approximately eight
hours of continuously use.
