Chatillon DG-200 - Page 7

DG Series User Manual 7
DIMENSION
1.75 in
(44.5 mm)
#10-32 UNF
Mounting Holes
(4 Locations)
3.85 in
(97.8 mm)
9.5 in
(241.3 mm)
4.45 in
(113.0 mm)
2.7 in
(68.6 mm)
5.0 in
(127.0 mm)
11.0 in
(279.4 mm)
5/16-18 UNC
0.38” Long
1.0 in
(25.4 mm)
E96-331
1.0 in
(25.4 mm)
0.6 in
(15.2 mm)
2.7 in
(68.6 mm)
2.2 in
(55.9 mm)
