Chatillon DG-200 - Specifications

6 DG Series User Manual
SPECIFICATIONS
Accuracy: +0.5% of Full Scale
Overload Capacity: 110% of Rated Capacity
Maximum Overload: 150% of Rated Capacity
Tare Capacity: 10% of Rated Capacity
Dial Resolution: 0.5% of Full Scale
Deection: 10mm(.394inches)atFullScale
OperatingTemperature: +40°Fto+110°F(+5°Cto+45°C)
InstrumentWeight: 4.7lbs(2.12kg)
ShippingWeightwithcase: 8.4lbs(3.80kg)
Warranty: 2 Years
ORDERING
Dial Style - LBF
Model Capacity
DG-200 200 x 1 lbf
DG-300 300 x 1.5 lbf
DG-400 400x2lbf
DG-500 500 x 2.5 lbf
Dial Style - KGF
Model Capacity
DG-100KG 100 x 0.5 kgf
DG-250KG 250 x 1.25 kgf
Dial Style - N
Model Capacity
DG-1000N 1000 x 5N
DG-2500N 2500 x 12.5N
Accessories
Item No. Description Standard
SPK-FMG-008B Adapter, Chisel Point Yes
SPK-FMG-009B Adapter, Point Yes
SPK-FMG-010B Adapter, Notch Yes
SPK-FMG-011B Adapter, Flat Yes
SPK-FMG-012C Hook Yes
SPK-FMG-013B ExtensionRod,6” Yes
NC002728 Carrying Case Yes
NC002500 Hook, Snap Clip Option
NC00721 V-Notch, Small Option
NC00725 V-Notch, Large Option
NC002844  GraspingCable Option
SPK-DG-HANDLE Handle Assembly Option
SPK-FMG-142 CurvedCompressionPlate Option
SPK-FMG-143 CompressionPlate,Circle Option
SPK-FMG-144 PalmFixture Option
SPK-FMG-145 RectanglePlate,large Option
SPK-FMG-146 RectanglePlate,small Option
NC002845  SoftCarryingCase Option
Note:Threadedxturesare5/16-18.
