DG Series User Manual 9
1 NC002689 Plate, Upper Support
2 NC002690 Plate, Lower Support
3 NC002681 Frame, Upper Support
4 NC002680 Frame, Lower Support
5 910-04-001 Ball Bushing
6 900-46-010 Retaining Ring
7 21047 Screw, #10-32 x 1/2 Flat Head
8 7970 Nut, 1/4-20 Hex
9 NC002685 Main Shaft
10 NC002684 Calibrator
11 NC002663 Support, Spring, Medium
12 NC002682 Support, Spring, Large
13 3168 Nut, #6 Hex
14 10390 Washer, #6 Lock
15 NC002683 Bearing Support
16 NC002668 Ball Bearing, Radial
17 E08-250 Screw, #1/4-20 x 1/2 Pan Head
18 NC002692 Spring Support, Calibrator
19 3127 Set Screw, #10-32 x 1/4
20 NC000124 Screw, #6-32 x 1 SHC
21 NC002688 Taper Pin, #2 x 1
22 E08-256 Screw, 1/4-28 x 1 SHC
23 900-30-021 Washer, 1/4 Flat
24 900-08-023 Set Screw, #6-32 x 1/4
25 NC002677-09 Dial Indicator, 200 lbf (DG-200)
NC002677-10 Dial Indicator, 300 lbf (DG-300)
NC002677-11 Dial Indicator, 400 lbf (DG-400)
NC002677-12 Dial Indicator, 500 lbf (DG-500)
NC002677-21 Dial Indicator, 100kgf (DG-100KG)
NC002677-22 Dial Indicator, 250 kgf (DG-250KG)
NC002677-32 Dial Indicator, 1000N (DG-1000N)
NC002677-33 Dial Indicator, 2500N (DG-2500N)
26 NC002674 Spring, Compression
27 NC002672 Bracket, Maximum Capture
28 NC002673 Plate, Maximum Capture
29 E08-241 Screw, #4-40 x 3/16 Pan Head
30 E08-252 Screw, #4-40 x 5/16 Round Head
31 NC002691 Threaded Bushing
32 9766 Washer, Lock 1/4 ID
33 NC002730 Top Housing
34 NC002731 Bottom Housing
35 03-90041 Screw, #6-32 x 5/16 Pan Head
36 E08-251 Screw, #6-32 x 3/4 Pan Head
38 NC002734-1 Main Spring, 200 lbf (DG-200
NC002734-2 Main Spring, 300 lbf (DG-300
NC002734-3 Main Spring, 400 lbf (DG-400
NC002734-4 Main Spring, 500 lbf (DG-500
NC002734-5 Main Spring, 100 kgf (DG-100KG
NC002734-6 Main Spring, 250 kgf (DG-250KG)
NC002734-7 Main Spring, 1000N (DG-1000N)
NC002734-8 Main Spring, 2500N DG-2500N)
39 SPK-DG-200 Trim Spring Set, 200 lbf (DG-200)
SPK-DG-300 Trim Spring Set, 300 lbf (DG-300)
SPK-DG-400 Trim Spring Set, 400 lbf (DG-400)
SPK-DG-500 Trim Spring Set, 500 lbf (DG-500
SPK-DG-100KG Trim Spring Set, 100 kgf (DG-100KG
SPK-DG-250KG Trim Spring Set, 250 kgf (DG-250KG
SPK-DG-1000N Trim Spring Set, 1000N (DG-1000N)
SPK-DG-2500N Trim Spring Set, 2500N (DG-2500N)
45 NC002621 Label, Capacity
53 NC002678 Latch, Pawl Assembly
54 E02-235 Split Lock Washer, #4
55 E02-236 Washer, Flat, #5
Ref. Item No. Description
Ref. Item No. Description
SPARE PARTS LIST
