EXPLODED VIEWS AND SERVICE PARTS LISTS
EN
| Intelect
®
Legend 2 - Service Manual DOMESTIC 65
EXPLODED VIEWS and SERVICE PART LISTS
TOP DISPLAY SUB ASSEMBLY: SP-12-5002
ITEM N° Service Part n° Description Qty
1 SP-12-5006 SERVICE PART G16 BUTTON TOP SUB ASSEMBLY 2
2 G16-4451-SP SERVICE PART MOB2 LED DIFFUSER KNOB 1
3 14-1041-SP SERVICE PART KB30X8 PLASTIC TORX SCREW x 5 8
