19
4. CONFIGURATION
The Configuration key is used to configure the device. This must be done before each new type of measurement. The con-
figuration remains in memory, even after the device is switched off.
4.1. CONFIGURATION MENU
The arrow keys (,, , ) are used to navigate in the Configuration menu and to parameterize the device.
A value that can be modified is flanked by arrows.
Most of the time, confirmation (
) is necessary for the changes made by the user to be applied.
The return key ( ) is used to return to the main menu from a sub-menu.
Figure 8: the Configuration screen
4.2. DISPLAY LANGUAGE
To select the display language, press the yellow key under the corresponding icon on the screen (Figure 6).
The active language is identified by the icon on the yellow ground.
4.3. DATE/TIME
The menu defines the system date and time. The display is as follows:
Figure 17: Date/Time menu
With the Date/Time field highlighted in yellow, press
. To change a value, press or . To move from one field to another,
press or . To confirm, press
.
Proceed in the same way for the dating system (DD/MM/YY or MM/DD/YY) and the time system (12/24 or AM/PM). You see the
effect immediately in the display of the date.
To return to the Configuration menu, press .
Note: The date and time parameters cannot be configured while the device is recording, metering energy, or searching for tran-
sients, alarms, and/or inrush current acquisition.
