Chauvin Arnoux F405 - AC Voltage Measurement Characteristics

35
Note (1) - The display indicates "+OL" above +2000V and "-OL" below – 2000V in
REL mode
- Above 1000V, a repetitive beep indicates that the voltage being
measured is greater than the safety voltage for which the device is
guaranteed.
4.2.2 AC voltage measurement
Measurement
range
0.15 V to
99.99 V
100.0 V to
999.9 V
1000V RMS
1400V peak (1)
Specified
measurement
range (2)
0 to 100% of the measurement range
Uncertainties
from 0.15V to 9.99V
± (1% R + 10 pt)
from 10.00V to
99.99V
± (1% R +3 pt)
± (1% R +3 pt)
Resolution
0.01V
0.1V
1V
Input impedance
10MΩ
Note (1) - The display indicates "OL" above 1400V (in PEAK mode).
- Above 1000V, a repetitive beep indicates that the voltage being
measured is greater than the safety voltage for which the device is
guaranteed. The display indicates "OL"
- Bandwidth in AC = 3 kHz
Note (2) Any value between zero and the min. threshold of the measurement range
(0.15V) is forced to "----" on the display.
