4.2.18 Calculation of the power factor
Measurement range (1)
-1.00 to +1.00
Specified measurement range
0 to 50% of the
measurement range
50 to 100% of the
measurement range
Uncertainties (7)
± (3% R +3 pt)
± (2% R +3 pt)
Resolution
0.01
Note (1) - If one of the terms in the calculation of the power factor is displayed as
"OL", or forced to zero, the display of the power factor is an indeterminate
value "----".
Note (7) of the previous § apply.
Note 9 - Sign of the power factor according to the four-quadrant rule (§4.2.12):
Quadrant 1 : Power factor PF sign + (inductive system)
Cos Φ sign +
Quadrant 2 : Power factor PF sign - (capacitive system)
Cos Φ sign -
Quadrant 3 : Power factor PF sign + (inductive system)
Cos Φ sign -
Quadrant 4 : Power factor PF sign - (capacitive system)
Cos Φ sign +
Specific characteristics in MAX/MIN mode (from 10Hz to 1kHz):
• Uncertainties: add 1% R to the values in the tables above.
• Capture time: approximately 100ms.
4.2.19 Frequency measurements
4.2.19.1 C haracteris tics in voltage
Measurement range (1)
5.0 Hz to
999.9 Hz
1000 Hz to
9999 Hz
10.00 kHz to
19.99 kHz
Specified measurement
range
1 to 100% of the
measurement
range
0 to 100% of the measurement
range
Uncertainties
± (0.4% R + 1 pt)
Resolution
0.1Hz
1Hz
10Hz
