Technical Manual PRINTER CHD6800
12 © Computer Hardware Design
[CAUTION] * This command is made for compatibility with TH-582.
2.12 ESC d Print and feed paper
[FORMAT] <1B>H<64>H<n>
[RANGE] 0≦n≦255
[FUNCTION] Prints the data in the print buffer and feeds the paper [n x pixel line].
[CAUTION] * After printing is completed, the next print start position is set to the beginning of the line.
2.13 ESC i Full cut
[FORMAT] <1B>H<69>H
[RANGE] -
[FUNCTION] Sets full cut.
[CAUTION] * Paper must be fed 3 mm after printing to prevent paper jam.
2.14 ESC m Partial cut (one point left uncut)
[FORMAT] <1B>H<6D>H
[RANGE] -
[FUNCTION] Sets partial cut.
[CAUTION] * Paper must be fed 3 mm after printing to prevent paper jam.
2.15 ESC p Generate pulse
[FORMAT] <1B>H<70>H<m><n1><n2>
[RANGE] m - ignored
0≦n1≦FFH
n2 - ignored
[FUNCTION] Outputs the pulse specified by n1 to drawer kick-out connector pin 2.
[CAUTION] * The pulse ON time is n1 x 2 msec.
