2.46 GS ( k; fn = 45H QR code; Set error correction level (v2.0.0)
[FORMAT] <1D>H<28>H <6B>H xL xH cn fn n
[RANGE] (xL+xH x256) = 3; (xL = 3, xH = 0)
cn – 31H
fn – 45H
30H ≦ n ≦ 33H;
[DEFAULT] n = 30H
[DESCRIPTION] Sets error correction level for QR code.
n
Description
Approximate recoverable error amount
30H
Error correction level L
7%
31H
Error correction level M
15%
32H
Error correction level Q
25%
33H
Error correction level H
30%
2.47 GS ( k; fn = 50H QR code; Store data (v2.0.0)
[FORMAT] <1D>H<28>H <6B>H xL xH cn fn m d1 … dk
[RANGE] 4 ≦ (xL+xH x256) ≦ 7092 (0 ≦ xL ≦ 255, 0 ≦ xH ≦ 27)
cn – 31H
fn – 50H
m – index of stored QR code data
30H – index = 0
31H – index = 1 (v2.1.0)
d – 0H – FFH (binary data)
k - (xL+xH x256) – 3 (-3 for cn, fn and m)
[DESCRIPTION] Stores QR code data (d1 … dk) in QR code m area.
[CAUTION] * Highest supported QR level is 19. Max result QR size is 93x93 modules (QR pixels). Max
input data is 1903 digits (‘0’ – ‘9’), or 1153 alphanumeric chars, or 792 binary bytes, or
488 Kanji chars.
* If k > 1903, all data is dropped and no QR is printed.
* All QR data starting with m + 1 are cleared.
