Check Point 3000 - Installation Workflow

7
Installation Workflow
Installation specifications:
Appliances Appliance Orientation
Installation
Type
1530
1550
1570
1590
All 1500 appliances:
n LEDs are facing the rear, and ports
are facing the front of the shelf
n LEDs are facing the front, and ports
are facing the rear of the shelf
All 1500
appliances:
n Single
n Side
by
side
(SBS)
3100
3200
3600
3800
All3000 appliances:
LEDs are facing the rear, and ports are
facing the front of the shelf only
All3000
appliances:
n Single
n Side
by
side
(SBS)
Workflow:
1.
Install the appliance and power supply on the shelf.
2.
Install the shelf in the rack.
3.
Attach the cables and power supply cable to the appliance.
4.
Follow your rack mount instructions to attach the shelf to the rack.
