Check Point Power-1 - Power-1 9070 Front Panel

Front Panel Components
Power-1 Hardware Page 17
Power-1 9070 Front Panel
Key
Description
1
LCD display screen
2
Management connection port - Ethernet connection to a
remote management workstation
3
Synchronization port - for synchronizing with cluster members
or a high availability peer
4
Console port - for a serial connection to the appliance using a
terminal emulation program such as HyperTerminal
5
Screen operation keys
6
Power indicator LED
7
USB ports
8
Future expansion slot
9
Expansion line card exp1 (2 or 4 ports)
10
Built in Ethernet ports (Lan1 - Lan8)
11
Expansion line card exp2 (2 or 4 ports)
12
Hard disk drive
