CHERNE Test-Ball - Page 41

41
Size Usage Range Maximum Allowable Back Pressure
Part #
Nominal
Size
Inches (mm)
Minimum
Diameter
Inches (mm)
Maximum
Diameter
Inches (mm)
Air
Pressure
PSI (bar)
Head
Pressure
Feet (Meters)
Required Inflation
Pressure
PSI (bar)
Single-Size Muni-Ball® Plugs*
262008 1½” (40) 1.49” (38) 1.88” (48) 22 (1,5) 50 (15) 40 (2,8) 262010 2” (50) 1.88” (48) 2.25” (57) 22 (1,5) 50 (15) 40 (2,8) 262021 3” (75) 2.62” (67) 3.25” (83) 22 (1,5) 50 (15) 40 (2,8) 262048 4” (100) 3.25” (83) 4.25” (108) 22 (1,5) 50 (15) 40 (2,8) 262064 6” (150) 4.5” (114) 6.25” (159) 13 (0,9) 30 (9.1) 35 (2,4) 262080 8” (200) 7” (178) 8.25” (210) 13 (0,9) 30 (9.1) 35 (2,4) 262110 10” (250) 9” (229) 10.25” (260) 13 (0,9) 30 (9.1) 35 (2,4) 262129 12” (300) 10.5” (267) 12.25” (311) 13 (0,9) 30 (9.1) 35 (2,4) 262137 15” - 16” (375 - 400) 14” (356) 16.25” (413) 13 (0,9) 30 (9.1) 35 (2,4) 262188 18” (450) 17.5” (445) 19.85” (504) 13 (0,9) 30 (9.1) 25 (1,7) 262218 21” (525) 18.85” (479) 21.38” (543) 13 (0,9) 30 (9.1) 25 (1,7) 262242 24” (600) 21.95” (558) 24.9” (632) 13 (0,9) 30 (9.1) 25 (1,7)
WARNING: Plugs must be braced while in use.
