48
Size Usage Range Maximum Allowable Back Pressure
Part #
Nominal
Size
Inches (mm)
Minimum
Diameter
Inches (mm)
Maximum
Diameter
Inches (mm)
Air
Pressure
PSI (bar)
Head
Pressure
Feet (Meters)
Required Inflation
Pressure
PSI (bar)
i-series™ Test-Ball® Plugs
395088 4” - 8” (100-200) 3.6” (92) 8.25” (210) 13 (0,9) 30 (9.1) 30 (2,1)
395128 6” - 12” (150-300) 5.75” (145) 12.25” (310) 13 (0,9) 30 (9.1) 30 (2,1)
395168 8” - 16” (200-400) 7.5” (186) 16.25” (413) 13 (0,9) 30 (9.1) 30 (2,1)
395248 12” - 24” (300 - 600) 11” (279) 24.25” (616) 13 (0,9) 30 (9.1) 30 (2,1)
395488
24” - 48”
(600 - 1200)
20.5” (521) 50” (1270)
SEE DATA
BELOW
SEE DATA
BELOW
22 (2,5)
at 24” (600) 15 (1,0) 35 (11)
at 30” (750) 13 (0,9) 30 (9.1)
at 36” (900) 12 (0,83) 28 (8.4)
at 42” (1050) 11 (0,76) 25 (7.6)
at 48” (1225) 10 (0,7) 23 (7)
at 48” DI (1225) 10 (0,7) 23 (7)
375608
30” - 60”
(700 - 1500)
26.5” (675) 60.5” (1537)
SEE DATA
BELOW
SEE DATA
BELOW
22 (2,5)
at 30” (750) 15 (1,0) 35 (11)
at 36” (900) 15 (1,0) 35 (11)
at 42” (1050) 15 (1,0) 35 (11)
at 48” (1225) 13 (0,9) 30 (9.1)
at 48” DI (1225) 13 (0,9) 30 (9.1)
WARNING: Plugs must be braced while in use.
