50
Size Usage Range Maximum Allowable Back Pressure
Part #
Nominal Size
Inches (mm)
Minimum
Diameter
Inches (mm)
Maximum
Diameter
Inches (mm)
Air
Pressure
PSI (bar)
Head
Pressure
Feet (Meters)
Required Inflation
Pressure
PSI (bar)
Air-Loc® Leak Locator Plugs (Front Plug)
267068 6” - 10” (150 - 250) 5.5” (140) 10.3” (260) 13 (0,9) 30 (9) 30 (2,1)
267088 8” - 12” (200 - 300) 7” (178) 12.3” (312) 13 (0,9) 30 (9) 30 (2,1)
267128 12” - 18” (300 - 450) 10.75” (273) 18.8” (478) 13 (0,9) 30 (9) 25 (1,7)
401308
15” - 30”
(375 - 750)
14.5” (368) 30.5” (775) See chart below* 25 (1,7)
at 15” (375) 17 (1,2) 40 (12)
at 18” (450) 13 (0,9) 30 (9)
at 21” (525) 13 (0,9) 30 (9)
at 24” (600) 11 (0,76) 25 (7.6)
at 30” (750) 11 (0,76) 25 (7.6)
401428
24” - 42”
(600 - 1050)
22.5” (570) 42.5” (1080) See chart below* 25 (1,7)
at 24” (600) 15 (1,0) 35 (11)
at 30” (750) 13 (0,9) 30 (9)
at 30” DI (750) 13 (0,9) 30 (9)
at 36” (900) 11 (0,76) 25 (7.6)
at 42” (1050) 9 (0,62) 20 (6.1)
WARNING: Plugs must be braced while in use.
